Disc separator is widely used in the pre-concentration of starch milk, starch milk separation, gluten concentration, intermediate concentration (clarification) and other sections.
1. The upper suspension drive mode is adopted to optimize the working conditions of the bearing and the spindle, and the service life is greatly improved;
2. The drum and disc have large diameter, large processing capacity and good separation effect;
3, The use of large aperture nozzle with cam lock, easy to disassemble, not easy to block, to ensure good continuous performance;
4. The rotor is tested by high-precision dynamic balance and the equipment runs smoothly;
5, Bearing point is equipped with temperature sensor, real-time monitoring of bearing operating status;
6. The spindle assembly is equipped with a vibration sensor to monitor the running status of the equipment in real time.
Model | MH30 | MH36 | MH38 |
Maximum throughput (m3/h) | 115 | 225 | 260 |
Spindle speed (RPM) | 3300（Max） | 2900（Max） | 2900（Max） |
Number of nozzles（pcs） | 20 | 30 | 30 |
Drum inner diameter (mm) | 780 | 940 | 990 |
Motor power (kW) | 110/132 | 220/250 | 250 |
Dimensions (mm) | 3050×1570×2420 | 3400×1780×2850 | 3400×1780×2850 |
