The QZ- series grivity curved screen is used in starch plant, for corn, germ, fiber washing, dehydration and separation sections.
It is made of stainless steel wedge rod together, with a certain radian concave screen surface, wet material applied to high throughput screening applications, a variety of material screening, separation, dehydration, washing and extraction of solid impurities the removal, the equipment used for corn starch industry dehydration, dehydration and washing fiber separation germ. Is an ideal screening equipment in starch industry, can also be used in other industries.
Main specifications and technical parameters
Model Item | QZ-800 | QZ-1000 | QZ-1200 | QZ-1500 | QZ-1640 | QZ-1760 | QZ-2000 |
Screen length(mm) | 800-1600 | 800-1600 | 800-1600 | 800-1600 | 800-1600 | 800-1600 | 800-1600 |
Screen width (mm) | 800 | 1000 | 1200 | 1500 | 1640 | 1760 | 2000 |
Screen radius (mm) | 760 | 1375 | 1375 | 1528 | 1528 | 1528 | 1528 |
Screen mesh (mm) | 0.16~3.0 |
capacity (m3) | 25-80 | 35-100 | 40-120 | 50-150 | 55-165 | 60-175 | 65-200 |
